SYSTEM R-C2
Currently the most innovative automation for milled parts. Produce finished parts automatically.
The vice grips the blanks directly in the magazine. The vice is placed in the machine with the blank as a pallet.
PROMRO Hybrid - the No. 1 robot cells in the R-C2 system
ROBOT CELLS HYBRID TA
Benefit from all the advantages of the R-C2 system - 4 sizes
The PROMRO TA hybrid robot cells support all the functions of the GRESSEL R-C2 system. Particularly suitable where space is limited. With medium and long milling times and small to medium-sized workpieces, impressively long unmanned times can be realized with the TA magazine. long unmanned times can be realized with the TA magazine.
Are you planning to automate your machining center?
Let us show you PROMRO Hybrid with System R-C2 now - so you won't regret it later!
Technical data Hybrid TA
| Hybrid 25 TA 900 | Hybrid 25 TA 1200 | Hybrid 50 TA 1200 | Hybrid 50 TA 1600 | |
|---|---|---|---|---|
| max. payload robot [kg] | 25 | 25 | 50 | 50 |
| max. workpiece weight [kg] | 6,5 | 6,5 | 33 | 33 |
| Magazine | TA Tables | TA Tables | TA Tables | TA Tables |
| Number of tables | 2 | 2 | 2 | 2 |
| Table size [mm] | 2 x 900 x 550 | 2 x 1200 x 550 | 2 x 1200 x 700 | 2 x 1600 x 700 |
| max. magazine area [m²] | 1 | 1,3 | 1,7 | 2,2 |
| Unmanned time [h] * | follows | follows | follows | follows |
| Stations | Re-Grip station, 6-sided station, Blow-off box | Re-Grip station, 6-sided station, Blow-off box | Re-Grip station, 6-sided station, Blow-off box | Re-Grip station, 6-sided station, Blow-off box |
| Lining parts | ●●○ | ●●○ | ●●○ | ●●○ |
| Shaft parts | ○○○ | ○○○ | ○○○ | ○○○ |
| Cubic parts | ●●● | ●●● | ●●● | ●●● |
| Saw cuts | ●●● | ●●● | ●●● | ●●● |
| Castings | ●●○ | ●●○ | ●●○ | ●●○ |
| for machining center |  | | | |
| Software Professional | | | | |
| Job manager | | | | |
| Multi Batch | | | | |
| Onepanel | | | | |
*) max. unmanned time in hours for parts 100x100mm and milling time 10min
